Memmert CO₂ Incubator ICO150med 156 litres, 230/115 V, 50/60 Hz, with CO₂ sensor
Product overview
The Memmert CO₂ Incubator ICO150med is a Class IIa medical device designed to provide and maintain constant ambient conditions for in-vitro fertilisation (IVF) applications. With a capacity of 156 litres, it offers precise control over temperature and CO₂ levels, ensuring optimal conditions for cell and tissue cultures.
Key Features:
- Brand: Memmert
- Model: ICO150med
- Capacity: 156 litres
- Temperature Range: +18°C to +50°C
- CO₂ Control: 0–20% with dual-beam NDIR sensor
- Humidity Control: Up to 93% RH with optional K7 module
- Power Supply: 230/115 V, 50/60 Hz
- Interior Dimensions: 560 x 700 x 400 mm
- Exterior Dimensions: 719 x 1070 x 591 mm
- Sterilisation: 60 minutes at 180°C (including sensors)
- Control Interface: TwinDISPLAY with intuitive controls
- Safety Features: Battery-buffered ControlCOCKPIT, FDA-compliant data logging, alarm notifications
This incubator is ideal for laboratories requiring reliable and precise environmental conditions for sensitive biological samples.
Frequently Asked Questions
1. What is the Memmert CO₂ Incubator ICO150med 156 litres, 230/115 V, 50/60 Hz, with CO₂ sensor used for?
It is a Class IIa medical device designed to provide and maintain constant ambient conditions for in-vitro fertilisation (IVF) applications. With a capacity of 156 litres, it offers precise control over temperature and CO₂ levels, ensuring optimal conditions for cell and tissue cultures.
2. Is this product suitable for laboratories requiring re?
Yes. It is designed for laboratories requiring re, and offers a capacity of 156 litres and a CO₂ control of 0–20% with dual-beam NDIR sensor to support this kind of work.
3. What capacity and CO₂ control does this product have?
It has a capacity of 156 litres, a CO₂ control of 0–20% with dual-beam NDIR sensor and a humidity control of up to 93% RH with optional K7 module.
4. What temperature range and control interface does this product offer?
It offers +18°C to +50°C, twinDISPLAY with intuitive controls, battery-buffered ControlCOCKPIT, FDA-compliant data logging, alarm notifications and fully insulated stainless steel door and heated inner glass door.
Product Specifications
- HS Code #84198998
- CO₂ range0 ... 20 %
- Depth int.400 mm
- Ext. dim. (WxDxH)719 x 591 x 1,070 mm
- Ext. depth591 mm
- Ext. height1070 mm
- Ext. width719 mm
- Power supply frequency50/60 Hz
- Height int.700 mm
- Int. Dim. (WxDxH)560 x 400 x 700 mm
- Int. width560 mm
- Material interiorStainless steel
- Max. CO₂20 %
- Max. no. of inserts10
- Max. O₂20 %
- Max. relative humidity93 %
- Max. temperature50 °C
- Max. voltage230 V
- Min. CO₂0 %
- Min. O₂1 %
- Min. temperature+5 °C
- Nominal capacity156 l
- O₂1 ... 20 %
- Power supply230 V, 50/60 Hz
- Rated capacity1.50 kW
- Relative humidity93 %
- Temperature stability±0,1 K
- TemperatureRT
- TemperatureRT+5 ... 50 °C
- TypeICO150med
- Type of auxiliary energyMains connection
- UNSPSC41104425
- Weight90 kg
